Hammond 1593ARIR10 Infrared End Panel 10-Pack, Red Polycarbonate
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- Pack of 10 infrared end panels for 1593AR enclosures
- Red polycarbonate, UL94 V-0
- 69 x 22 x 2 mm (2.71 x 0.86 x 0.07 in)
- Fits 1593ARBK, 1593ARGY and 1593ARTBU
- Supplied in a bag; 0.04 lbs
- RoHS and REACH compliant
The 1593ARIR10 is a pack of 10 infrared end panels for 1593AR hand held instrument enclosures. It lets designers replace the standard front or rear panel of a 1593AR case with an infrared panel, for devices that need an IR window at the end of the enclosure.
Each panel is molded from red polycarbonate with a UL94 V-0 flammability rating and measures 2.71 in x 0.86 in x 0.07 in (69 mm x 22 mm x 2 mm). The series lists infrared panels as sold in packs of 10, and the pack ships in a bag weighing 0.04 lbs (0.02 kg).
The panels suit the 1593ARBK, 1593ARGY and 1593ARTBU enclosures, which have two removable end panels. The compatibility table for 1593AR also lists 1591TS100 and 1591TS100BK assembly screws, SC519-50 PC board mounting screws and 1593ARAL10 aluminum panels.
The 1593AR case is listed at 75 mm x 74 mm x 27 mm and is molded in satin-textured general purpose ABS. Its assembly screws, 1591TS100 and 1591TS100BK, are #4 x 1/2" (12.7 mm) flat head self-tapping screws.
The 1593ARIR10 is RoHS and REACH compliant and carries UPC 623980562575 and UNSPSC 39121301.
Ideal For
- IR windows for hand held remotes and instruments
- Replacement end panels for 1593AR cases
- Infrared communication devices
Overview
| Type | End panels, infrared |
| Series | 1593 Series ABS Plastic Hand Held/Instrument Enclosures |
| Description | infrared panels for 1593 enclosures, 10-pack |
| Part Number | 1593ARIR10 |
| Pack Quantity | 10 panels |
| Short Description | 1593AR INFRA RED ENDPANELS |
Dimensions
| Size (L X W X H) | 2.71 in x 0.86 in x 0.07 in (69 mm x 22 mm x 2 mm) |
Identifiers
| UPC | 623980562575 |
| UNSPSC | 39121301 |
Compatibility
| IR Panels (10-pack) | 1593ARIR10 |
| Aluminum Panels (10-pack) | 1593ARAL10 |
| Black Assembly Screws (100-pack) | 1591TS100BK |
| Silver Assembly Screws (100-pack) | 1591TS100 |
| PC Board Mounting Screws (50-pack) | SC519-50 |
| For Enclosure Part Numbers Beginning With | 1593AR |
Packaging & Shipping
| Packaging Type | bag |
| Shipping Weight | 0.04 lbs (0.02 kg) |
Construction & Finish
| Color | Red |
| Material | Polycarbonate |
| Flame Rating | UL94 V-0 |
Compliance & Certifications
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
What is the 1593ARIR10?▾
A 10-pack of infrared end panels for 1593AR hand held enclosures.
What material and colour are the panels?▾
Red polycarbonate, rated UL94 V-0.
How big is each panel?▾
2.71 in x 0.86 in x 0.07 in (69 mm x 22 mm x 2 mm).
Which enclosures does it fit?▾
1593ARBK, 1593ARGY and 1593ARTBU.
