Hammond 1455RAL-10 Clear Anodized Aluminum End Panels for 1455R, 10-Pack

The 1455RAL-10 is a 10-pack of clear anodized aluminum end panels for 1455R extruded aluminum enclosures. The series ordering table lists these panels under "Aluminum End Panels (For Use With Metal End Plate Enclosures)" for part numbers starting with 1455R, making them the spare or replacement flat metal ends for 1455R boxes built with metal end plates.

Metal-end 1455 enclosures ship with two flat aluminum end panels colour matched to the housing, used together with open plastic bezels. In the clear finish, these panels match the clear anodized metal-end 1455R models such as 1455R1601 and 1455R2201. The series literature notes that extra end panels are sold in 10-packs in clear, black, red or blue anodized finishes, and that accessory panels and bezels allow for mixing and matching of colours.

Having a 10-pack on hand is useful for OEM production builds, multi-unit projects and service spares. The other finishes in this line are 1455RALBK-10, 1455RALBU-10 and 1455RALRD-10.

The panels are aluminum, colour Clear (Anodize). The 1455RAL-10 is RoHS and REACH compliant, packed in a bag, and has a shipping weight of 0.44 lbs (0.20 kg). The 1455R enclosure body is 165.00 mm wide by 30.50 mm deep in the series table, offered in 160 mm and 220 mm lengths.
