Hammond 1427MBB 5.3 in Centers Metal Bar Handle, All-Black

The 1427MBB is a 5.3 in metal bar handle with plastic end posts from the 1427 Metal Handles w/ Plastic Posts series, made for OEM engineers, panel builders and electronics enclosure users who need a durable pull or carrying handle. The 5.30 in (135 mm) hole spacing sits between the 5 in and 6 in sizes, useful when a panel layout or existing hole pattern calls for that exact spacing.

The handle uses a heavy duty extruded anodized aluminum bar held between rugged end posts made of Polyamid with 30% reinforced glass fiber and molded-in brass inserts, giving it a modern style. This version pairs black end posts with a black extruded aluminum bar for an all-black look that suits dark panels and cases. The same size is also offered as 1427MBC and 1427MGC, since the series provides three colour versions for each size.

Key dimensions for this size:

• Mounting hole centers: 5.30 in (135 mm)
• Overall size (L x W x H): 6.06 in x 0.55 in x 1.64 in (154 mm x 14 mm x 42 mm)
• Handle depth: 1.64 in (42 mm); handle width: 0.52 in (13 mm)
• Overall length on drawing: 153.85 mm; bar length between posts: 117.48 mm

The posts are tapped M4-0.7 (M4x0.7-6H on the drawing) and the handle ships with its hardware: 2 countersink M4 x 10 screws and 2 washers. It is sold singly, so order one per handle position. The 1427MBB is RoHS and REACH compliant, packed in a bag, with a shipping weight of 0.11 lbs (0.05 kg).
