Fender Princeton* · Guitar Amp Replacement

Brand: Hammond Manufacturing · 8 part numbers

■Fender single ended Tweed*, 5 Watts, Fender Princeton* 12 Watts, Princeton Reverb* 12 - 15 Watts
■Physically, parts were designed to look similar to original factory units (where possible).
■Material used & design specs. were kept as close as possible to the original part to preserve the stock "tone".
■See drawing for specifications and size.
■Do you know of any models we don't list? If so please contact us for information. We do have a great deal available when you help us add any missing antique tube amp transformer or choke for Fender.
■Contact us at Guitar@hammfg.com

from $19.06

7 of 8 part numbers priced · in stock · ships by ground · volume pricing on request

Choose part number & buy now Request a quote

Specification sheet (PDF) (224) 955-1644

Part details Features Documents Additional information

Configure & price

Find your Guitar Amp Replacement part number

Filter 1 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.

1 of 1 part numbers

1760EP

QuoteRequest a quote

Dimension tables (inches / mm)

Power Transformer Domestic 120V, 60 Hz.

Fender* No: 125P1B, 022772 Core: Bobbin

col1	col2	Price	Order
Part No.	290AX	$90.37In stock	Buy now

Power Transformer International 100/110/120/210/220/230/240V, 50/60 Hz.

Fender* No: 125P1B, 022772 Core: Bobbin

col1	col2	Price	Order
Part No.	291AEX	$104.79In stock	Buy now

Output Transformer - 3.2 Ohms

Fender* No: 125A35A, 022905, 125A3A Core: Bobbin

col1	col2	Price	Order
Part No.	1750C	$36.09In stock	Buy now

Output Transformer - 3.2, 8, 16 Ohms

Fender* No: 125A35A, 022905, 125A3A Core: Bobbin

col1	col2	Price	Order
Part No.	1760C	$45.12In stock	Buy now

Output Transformer, 8 Ohms

Fender* No: 125A10B, 022913 Core: Bobbin

col1	col2	Price	Order
Part No.	1750E	$41.01In stock	Buy now

Output Transformer - 4, 8, 16 Ohm

Fender* No: 125A10B, 022913 Core: Bobbin

col1	col2	Price	Order
Part No.	1760E	$47.77In stock	Buy now

Output Transformer - 4, 8, 16 Ohm (paper wound)

Fender* No: 125A10B, 022913 Core: Bobbin

col1	col2	Price	Order
Part No.	1760EP	Quote	Quote

These part numbers are quoted per order — send us the quantities and we'll price them within one business day.

Choke - 4H @ 50 mA DC

Fender* No: 125C3A, 022707

col1	col2	Price	Order
Part No.	194A	$19.06In stock	Buy now

Features

Click Part No , below, for details (e.g., Product drawings, assembly instructions, ship weight)

■Fender single ended Tweed*, 5 Watts, Fender Princeton* 12 Watts, Princeton Reverb* 12 - 15 Watts
■Physically, parts were designed to look similar to original factory units (where possible).
■Material used & design specs. were kept as close as possible to the original part to preserve the stock "tone".
■See drawing for specifications and size.
■Do you know of any models we don't list? If so please contact us for information. We do have a great deal available when you help us add any missing antique tube amp transformer or choke for Fender.
■Contact us at Guitar@hammfg.com
■DISCLAMER: * Hammond Mfg. is not affiliated with Fender Musical Instruments Corp. Amplifier model names are trademarks of the Amplifier companies and are just listed here for reference purpose only.
